Product type: Single relay, miniature power relay with plug-in connection with multi-layer gold-plated contacts.

Electrical characteristics

Input data: The input voltage is rated at 48V DC and the input voltage range is 28.8V DC to 132V DC. The drive is monostable and non-polarized, with a typical input current of 8mA at a rated input voltage, a coil resistance of 6000Ω±10% at 20°C, and a maximum power consumption of 0.17W under the specified conditions.

Output data: 1 changeover contact of the contact switching type, single contact of the switching contact type, contact material of AgSnO, hard gold plating. Under normal conditions, the maximum switching voltage is 30V AC, 36V DC, the minimum switching voltage is 100mV (at 10mA), the limited continuous current and the maximum inrush current are both 50mA, the minimum switching current is 1mA (at 24V), and the maximum power rating (resistive load) is 1.2W (24V DC). When the gold plating layer is destroyed, the maximum switching voltage is 250V AC/DC, the minimum switching voltage is 5V (at 100mA), the limited continuous current is 6A, the minimum switching current is 10mA (at 12V), the maximum rated power value (resistive load) will change accordingly, such as 140W (24V DC), 20W (48V DC), etc., and the switching capacity is 2A (at 24V, DC13), 0.2A (at 110V, DC13), etc.
