Electrical characteristics
Input data: Rated input voltage is 24V DC and input voltage range is 18.7V DC to 46.8V DC at 20°C. The drive mode is monostable and polarized, with a typical input current of 42mA, a typical response time of 13ms, and a typical release time of 14ms at the rated input voltage. The protection circuit is a freewheeling diode and the status is shown as a yellow LED.
Output data: 4 changeover contacts (4PDT) for contact switching, single contact type for switching, contact material for hard gold-plated AgNi. Under normal conditions, the maximum switching voltage is 30V AC, 36V DC, the minimum switching voltage is 2V (at 24mA), the limited continuous current and the maximum inrush current are both 50mA, the minimum switching current is 2mA (24V DC), and the maximum power rating (resistive load) is 1.2W (24V DC)
