      Autonics Light curtains BWPK25-05
      • Autonics Light curtains BWPK25-05

      Autonics Light curtains BWPK25-05

      ★ ★ ★ ★ ★ 4.9 0 Reviews Certified

      Model: BWPK25-05

      Order No: BWPK25-05

      SKU: 10000058435101

      Category: Light curtains

      Brand: AUTONICS

      Condition: New Sealed Under Guarantee

      Size: 0.00, 0.00, 0.00;

      Weight: 220.00g

      Product Selection Engineer: Zuohuiqin

      Leading

      Shipping

      QTY
      - +

      Customer Service Guarantee

      100% secure payment

      Quality Guarantee

      No Reason Returns

      Are you a Supplier?

      Join Us in Delivering Excellence Worldwide

      Apply to join

      You May Also Like

      Selling List

      Description Reviews
      BWPK25-05
      The BWPK series area sensor is made of high-strength PC/ABS (polycarbonate/acrylonitrile butadiene styrene) plastic with a flat, compact body (10mm). Screening indicators on the illuminator and receiver can clearly identify the working status, and the elimination of synchronous wiring makes installation and wiring simpler. The DIP switch can be used to switch between various functions and modes, including long/short range detection mode switching, anti-mutual interference function, Light ON/Dark ON switch, and filter indicator ON/blink options.
      BWPK25-05
      Sensing type Through-beam type(direct beam)
      Sensing distance Long distance mode: 0.1 to 3m
      Short distance mode: 0.05 to 1m
      Light source Infrared LED(850nm modulated)
      Optical axis pitch 25mm
      Number of optical axes 5
      Sensing height 100mm
      Power supply 12-24VDC ±10%(ripple P-P: max. 10%)
      Control output NPN open collector
      Operation mode Light ON/Dark ON(set by switch)
      Environment_Ambient illumination Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
      Environment_Ambient temperature -10 to 55℃, storage: -20 to 60℃
      Connection type Cable type(Ø4, 2m)
      Protection structure IP40
      Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH
      Min. sensing target Opaque materials of min. Ø35mm
      Response time Max. 30ms
      Material Case: Polycarbonate/Acrylonitrile butadiene styrene, Sensing part: Polymethyl methacrylate
      Cable specification Ø4.0mm, 4-wire, 2m(emitter: Ø4.0mm, 3-wire, 2m)
      (AWG 22, core diameter: 0.08mm, number of cores: 60, insulator out diameter: Ø1.25mm)
      Weight Approx. 220g(approx. 180g)
