The optical fiber transceiver is a 10/100M/1000M intelligent adaptive fast Ethernet photoelectric converter. It can transfer data between two different network transmission media, twisted pair and optical fiber. This photoelectric converter can extend the transmission distance of the network from 100m to 100Km, without the help of any other converter. At present, optical fiber transceivers are widely used in: homeland security, prisons, petrochemical industry, enterprises and banks, entertainment venues and hospitals, health monitoring centers, government and military, power plants, traffic monitoring, schools and other communication systems.
● 1x100BaseF(x) port+1x10/100BaseT(x)
● Ready to use, convenient and fast
● Meet the Ethernet access requirements of general application environments
Technical specifications | |
Ethernet Standard | IEEE802.3-10BaseT IEEE802.3u-100BaseTX/100Base-FX IEEE802.3x-Flow Control |
Interface | |
10/100Base ports | Port numbers: 2 |
Connector: 1*9 fixed Fx port(Single/multi-mode or SC/FC/ST port available) or RJ45 | |
Baud rate: 100Base-FX(fiber port), 10/100M for adaptive port | |
Terminal block for power input | BNC |
Communication distance | |
Twisted-pair | 100m(CAT5/CAT5e cable) |
Multimode fiber | 10/100Base multi-mode: 1310nm 2km |
Single mode fiber | 10/100Base single mode: 1310nm 20/40km; 1550nm 60/80km |
LED indicator lights | |
Front panel LED | Port light: LINK/ACT, SPEED |
Power LED: PWR | |
Power requirements | |
Power input | DC5V/ AC220V |
Full-load Consumption | <2.5w@full load |
Working Environment | |
Operating Temperature | 0°C~50°C |
Ambient Humidity | 5%~95%( non-condensing) |
Physical Characteristics | |
Shell | Aluminum alloy shell |
Installation | Desktop installation, support for wall mount and plug-in options |
Dimension | 95.0mm*26.0mm*70.0mm |
Industry standard | |
EMC | EN61000-4-2(ESD), Level 4 EN61000-4-3(RS), Level 4 EN61000-4-4(EFT), Level 4 EN61000-4-5(Surge), Level 4 EN61000-4-6(CS), Level 4 EN61000-4-8, Level 5 |
Impact | IEC60068–2-27 |
Falling | IEC60068-2-32 |
Shock | IEC60068-2-6 |
Warranty | |
Warranty period | 5 Years |
Certification | |
Certification | CE/FCC/RoHS |
